At Affinicom, we specialise in preparing detailed layout permit drawings essential for telecom infrastructure deployment. Our process involves using AutoCAD to develop accurate and jurisdiction-compliant plans that clearly represent the proposed work area. These layouts typically include:

Right-of-Way (ROW) boundaries

Property lines and parcel details

Existing structures and utilities along the proposed route

Proposed telecom infrastructure (OSP/ISP elements)

Relevant easements, setbacks, and access points

Our expertise ensures that each layout drawing meets the specific standards of local and state jurisdictions, serving as a critical component of the overall permit submission. The result is a comprehensive visual representation that supports both the permitting process and successful project execution.
